8 Core OS2 9/125 Singlemode MPO Male APC to LC UPC Breakout Fiber Patch Cord

Short Description:

Raw Materials: Corning Or YOFC fiber, Us kevlar

Fiber Mode: Singlemode 9/125 OS1/OS2

Length: Customized Length

Cable Diameter: 3mm

Cable Colors: Yellow or Customized

Using Life: 20 Years

MOQ: 1 PCS

Lead Time: 3 days

Country of Origin: China

Send email to us

Product Detail

Product Tags

Products Description

12 Cores MPO male to 4 x Duplex LC/UPC 9/125 Sibglemode Breakout Fiber Cable

MPO breakout cable, a cost-effective alternative to time-consuming field termination, is designed for high-density fiber patching in data centers which need space saving and reduce cable management troubles. It is optimized for 40G QSFP+ PLR4 to 10G SFP+ LR, 400G OSFP/QSFP-DD DR4 to 100G QSFP DR and 400G OSFP/QSFP-DD XDR4 to 100G QSFP FR optics direct connection and high-density data center applications.

Product Paramenters

Connector Type	MPO/male to 4 Duplex LC/UPC	Fiber Type	G657A1 9/125μm
Wavelength	1310/1550nm	Fiber Count	12 Fibers (Base-12)
Polish Type	APC (MPO) to UPC (LC)	Minimum Bend Radius	10mm
MTP Connector Count	1	LC Connector Count	4
MTP Connector IL	0.20dB Max	LC Connector IL	≤0.35dB
MTP Connector RL	≥60dB	LC Connector RL	≥50dB
Attenuation at 1310nm	≤3.5dB/km	Attenuation at 1550nm	≤3.5dB/km
Jacket OD	2.0mm	Cable Jacket	PVC/OFNR/LSZH/Plenum(OFNP)
Polarity	Type B
Installation Tensile Load	66 N
Tensile Strength (Long/Short Term)	200N/660N
Operating Temperature (° C)	-10~ + 70
Storage Temperature (° C)	-40 ~ +85
Package	1PC/bag

Features:

Double jacket sheath further protects network connections

Double jackets with greater pressure resistance protect the fiber core and increase the strength and durability of the fiber.

Excellent workmanship ensures stable transmission

Corninig MTP/LC cables provide state-of-the-art multi-fiber and mechanical properties.

MPO Connector Type

MPO connector can choose Male or Female

Application

Packing & Delivery

Packaging & Shipping

In order to ensure the safe arrival of your goods, I have multiple modes of transportation: sea and air. Sea freight will be longer than air freight, but air freight costs will be higher. The transportation method depends on your own choice.
