Outdoor IP67 SC UPC/APC Waterproof Hardened Adapter for MST Box Fiber Optic Terminal Equipment

Short Description:

Raw Materials: Corning Or YOFC fiber

Length: Customized Length

Cable Colors: Black or Customized

Using Life: 20 Years

MOQ: 10 PCS

Lead Time: 3 days

Country of Origin: China

Send email to us

Product Detail

Product Tags

Products Description

IP67 Waterproof Optitap SC Waterproof Hardened Connector Adapter

Mini SC LC MPO assemblies provide a robust and sealed connection solution for fiber to the home (FTTH) connectivity.
The Hardend connector end incorporates an LC SC MPO type connection within a slim, sealed, threaded polymer housing allowing easy connection to either a multi port terminal or in-line extension receptecal.
The SC LC MPO connectors mate to a standard adapter providing a common interface for FTTX applications.

Model Number:	Hardened Connector Adapter	Connector Type:	SC
Use:	FTTA, FTTX, FTTH	Length:	Customized
Place of Origin:	Guangdong, China	Brand:	OEM/ODM
Network:	Wireless Lan	Fiber Type:	Singlemode ; Multimode
Fiber count:	Simplex	Connector Polish:	UPC/APC/PC
Insertion loss:	≤0.1dB(UPC/PC); ≤0.15dB(APC)	Return loss:	SM ≥50; MM ≥30
Cable Diameter	4.8mm/5.0mm/7.0mm	Laying Method:	Indoor/Outdoor cabling
Operating Temperature (° C)	-10~ + 70	Storage Temperature (° C)	-40 ~ +85
Exchangeability	≤ 0.2dB
Cable Assemblies	Pigtail/Simplex/Duplex/Fan-out Patch cord

Appl ication

Provides superior weather resistance for FTTA and other outdoor applications;

Allows flexibility to use factory terminated assemblies or pre-terminated or field installed assemblies;

Suitable for FTTA and outdoor temperature extremes Ensures functionality in harsh weather environments;

Can be installs without special tooling; Threaded style coupling; Provides bend protection for installation and long term use.

Features

1. Compatible with Corning-Opti Tap and H-Connector; 2. Factory terminated for high performance; 3. Available with one or both ends connectorized; 4. Hybrid (one end with an Opti Tap Connector, one end with standard SC connector) available with or without pulling grip; 5. Available in dielectric or toneable; 6. Designed for aerial, direct-buried or duct installation; 7. IP-67 water and dust protection ; 8. -40℃~85℃ operating temperature;
