LC/SC/FC/ST Simplex OM3/OM4 Multimode Armored PVC (OFNR) 3.0mm Fiber Optic Patch Cable

Short Description:

Product Name: LC/SC/FC/ST Simplex MM OM3/OM4 Armored Fiber Optic Patch Cable

Raw Materials: Corning Or YOFC fiber, Us kevlar

Length: Customized Length

Cable Diameter: 3.0mm

Cable jacket: PVC(OFNR)/Plenum/LSZH

Cable Colors: Aqua, Grey, Yellow, Blue or Customized

Product Detail

Product Tags

Product Description

LC/SC/FC/ST OM3/OM4 50/125 Multimode Simplex Indoor Armored Fiber Optic Cable

Armored fiber optic cable with build-in metal armor can provide stronger protection of the optical fibers than standards fiber optic cables. The rugged armored cables allow optical fiber to be installed in the most hazardous areas, including environments with slight dust, oil, gas, moisture, or even damage-causing rodents.

Product Specification

Connector Type LC/SC/FC/ST Polish Type UPC to UPC
Fiber Mode OM3/OM4 50/125μm Wavelength 850/1300nm
Fiber Count Simplex  Polarity  A (Tx) to B (Rx)
Fiber Grade Bend Insensitive Minimum Bend Radius 10D/5D (Dynamic/Static)
Cable Diameter 3.0mm Cable Jacket  PVC(OFNR)/Plenum/LSZH
Cable Color Blue/Orange/Aqua/Yellow/Black Fiber Cords Structure Single Armored, Stainless Steel Tube
Tensile Loads (Long Term) 120N Tensile Loads (Short Term) 225N
Insertion Loss ≤0.3dB Return Loss ≥30dB
Operating Temperature -25~70°C Storage Temperature -25~70°C

Product Specification

Product Highlights

Tough Steel Tube Protects Network Connection Further

Stainless steel tube can provide good protection against optical fiber breakage and be used in a slight oil, gas and moisture environment, which ensure the operation of the network.


Meet the Various Indoor Installation Needs

Exceptional durability of armored fiber cables is suitable for network cabinet connection, ceiling channel wiring and under-floor wiring in data center.


Carrier-grade Cable with Guaranteed Quality

Superior cable assemblies reduce light loss during cable bending and easily meet your diverse cabling requirements.
